Simrad ST90 Installation Manual

442703/B
319
7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
AssigningfunctionstoF1,F2andF3ontheOperatingPanel
TheOperatingPanelisttedwiththreefunctionbuttons.Thebuttonsareidentiedas
F1,F2andF3.Eachbuttoncanbeassignedadedicatedfunction.
Context
TheOperatingPanelpageisusedtoselectwhich
physicalhardwarepanelyouuseonyourST90,and
toassignfunctionalitytotheprogrammablebuttons.
ThispageislocatedintheInstallationdialogbox.The
InstallationdialogboxislocatedontheSetupmenu.
ThethreefunctionbuttonsaregroupedwiththeScreen
Capturebutton.
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4Selectwhichoperatingpaneltouse.
5UnderButtonOptions,assignonefunctiontoeachfunctionbuttonontheoperating
panel.
6Atthebottomofthepage,selectApplytosaveyoursettings.
7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Settingtowork
