Simrad ST90 Installation Manual

356
442703/B
Relatedtopics
Settingtoworksummary,page242
TestingtheST90operationalfunctionality,page345
VerifyingST90operationbymeansoftheElementBITE
functionality
ThepurposeoftheElementBITE(ElementBuilt-InTestEquipment)dialogboxisto
allowon-linetestandvericationoftheindividualelementsinthetransducer.Itallows
youtoseeifthetransducerelementsareoperationalduringtransmissionandreception.
TheB-Scanpageallowsyoutomonitorthetimeseriesofdatathatisreceivedfromeach
oftheelementsintheST90transducer.Thestartsampleandthenumberofsamples
tobedisplayedareadjustable.
Prerequisites
TheST90isinstalledasspeciedinthismanual.
•TheST90isturnedon,anditisworkingnormally.
•TheST90isinNormalmode,butTXPowerissettoOfftopreventtransmission.
•Thetransducerisretractedtoitsupperposition.
•Thevesselisberthedoratsea.
Neithertoolsnorinstrumentsarerequired.
Caution
YoumustneversettheST90to"ping"unlessthetransducerissubmergedinwater.
Thetransducermaybedamagedifittransmitsinopenair.
Context
BymeansoftheElementBITE(ElementBuilt-InTestEquipment)functionality,youcan
easilydetermineiftheST90hardwareisoperational.Thefollowingpagesareprovided.
•Matrix
TheMatrixpageallowsyoutomonitortheaveragesignalvaluesorsignalphases
fromeachofthechannelsandtransducerelementsintheST90.Thepresentationis
providedonamatrixcorrespondingtotheelementlocationsinthetransducer.
