442703/B

485

Third-partydatagramformats

Topics

AtlasDepthdatagram,page485

FurunoGPhvedatagramformat,page485

HemisphereGNSSGPHEVdatagramformat,page486

AtlasDepthdatagram

AtlasDepthisaproprietarydatagramformatcreatedbyAtlasElektronik

(http://www.atlas-elektronik.com)toprovidethecurrentdepthfromtwochannels.

Format

Dyxxxxx.xxm

Description

1Dy:Channelnumber

•DA:Channelnumber1

•DB:Channelnumber2

2xxxxx.xxm:Depthinmetres

Relatedtopics

Third-partydatagramformats,page485

FurunoGPhvedatagramformat

FurunoGPhveisaproprietarydatagramformatcreatedbyFuruno(http://www.furuno.jp)

tocontainheaveinformation.

Note

Thedatagramformatdescribedhereremainsthepropertyoftheorganizationthat

denedit.Ifyouneedmoreinformationaboutthisformat,contacttheowner.

Format

$PFEC,GPhve,xx.xxx,A*hh<CR><LF>
