Hullunitfamiliarization
Theupperpartsofthehullunitincludethemechanicalgantry,thehoistmotorandthe
MotorControlUnit.
Thetransducershaftissupportedbythegantry,
andpenetratesthemountingange.Thecomplete
arrangementismountedontopoftheinstallationtrunk.
TheST90transducerisboltedtothebottomofthe
transducershaft.Thetransducercablesareplaced
insidetheshaft.
AHandcrankformanualhoistingandlowering
BTransducercablewithplug
CHoistingmotor
DMotorControlUnit
ETransducershaft
FTransducershaftsleeve
GMountingange
HInstallationtrunk
ITransducer
