88
442703/B
Abouttheoptionalgatevalve
Onsomevessels,additionaltransducerprotectionisrequired.Oneexampleisvessels
workinginarcticconditions.Itisimportantforthemtopreventicefromdamagingthe
transducer.Agatevalvecanthenbeaddedtothehullunitinstallation.Bymeansofa
mechanicalconstructionitshutsoffthebottomoftheinstallationtrunkwhentheST90is
notused.ThegatevalveisnotmanufacturedbyKongsbergMaritime.
ThegatevalveismanufacturedbyLK
Valves.
Gatevalve:DN500
Manufacturer:LKV alves
Manufacturer’swebsite:http://www.lk-
valves.com
Technicalinformationaboutthisunit
isnotincludedinthisST90Installation
Manual.Refertotherelevantend-user
documentationprovidedbythe
manufacturer.
Thegatevalveisplacedatthebottomof
thetransducerdock.Itwillthenincrease
thetotalheightofthehullunitinstallation.
Thehullunitlowersthetransducer
downtoaspecieddepthbelowthe
ship’shull.TheST94HullUnitlowers
thetransducerto2.1metresbelowthe
hull.Thesedepthsaredecreasedwith
thephysicalheightofthegatevalve.
Thedepthsarefurtherdecreasedwith
theheightofthemountingange.
TheST90allowsyoutodeneamiddle
positionforthetransducer.Whenyou
denethemiddleposition,youmust
takethetotalheightofthegatevalveand
themountingangeintoconsideration.
Theinstallationtrunkisnotusedwhen
agatevalveismounted.Theinstallation
trunkisthenreplacedwithatransducerdock.
Note
Itisveryimportantthatthegatevalvemechanismsareinterfacedwiththehullunit
controller.Whenthegatevalveisclosed,itmustnotbepossibletolowerthetransducer.
Whenthetransducerislowered,itmustnotbepossibletoclosethegatevalve.
SimradST90InstallationManual
