ØverlandUPC-5000PSeriallinesplitterdescription
TheØverlandUPC-5000Pisaseriallinesplitterwithtwoseparateinputsandfteen
outputs.
Dualpowerinputwithautoswitch.
ThetwoinputsAandBareseparatedwith
Aastheprimaryinput.Ifthereisdataon
bothAandBinputs,inputAisused.Input
BisusedonlyifinputAisidle.Thepower
supplyandbothsignalinputsaregalvanic
isolatedfromtheoutputs.
Alloutputsareshortcircuitprotected.
Informationfromthemanufacturer’ sdata
sheet,copiedMay2014
TheseriallinesplitteristtedwithaDINrailfor
easymountingandreplacement.
Note
Theseriallinesplitterrequiresadedicatedpowersupplyproviding15to30VDC.
Formoreinformationaboutthisseriallinesplitter,consultthemanufacturer’swebsite.
•Manufacturer:Øverland
•Manufacturer’swebsite:http://www.overland.no
Relatedtopics
ØverlandUPC-5000PSeriallinesplitterdescription,page195
ØverlandUPC-5000PTechnicalspecications,page196
ØverlandUPC-5000PConnections,page197
ØverlandUPC-5000PDimensions,page198
Aboutseriallinesplitters,page190
Cablelayoutandinterconnections
