442703/B

171

InstallingtheST90cables

Topics

Prerequisitesforcableinstallation,page171

InstallingtheST90topsidecables,page172

InstallingtheST90sonarroomcables,page175

ProcessorUnitrearconnectors,page177

OperatingPanelconnectors,page179

TransceiverUnitconnectors,page180

ACmainspowercable(3-phase)totheMotorControlUnit,page181

Prerequisitesforcableinstallation

CorrectwiringiscrucialfortheoperationalperformanceoftheST90.Electrical

connectionscanonlybemadebyskilledpersonnel(shipelectricians,techniciansor

engineers).Theinstallationshipyardmustpreparedetaileddrawingsoftheelectrical

system,andidentifyeachcable.Observethebasiccablerequirements.

Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe

normaltoolsforcableinstallationtasks.Thisincludesdifferentscrewdrivertypes,

pliers,spanners,acablestripper,asolderingiron,etc.Eachtoolmustbeprovidedin

varioussizes.Werecommendthatalltoolsaredemagnetizedtoprotectyourequipment.

Dependingonthetasksathand,additionaltoolsmayberequired.

Refertothecableplansandthelistofcables.Detailedinformationaboutcable

specications,terminationandconnectorsareprovidedintherelevantcabledrawings.

Unlessotherwisespecied,allcablesaresuppliedwiththeST90delivery.Inorderto

easetheaccessformaintenancepurposes,andtoallowforvibration,makesurethat

someslackisprovidedforeachcable.

Note

Allelectronicinstallationsandcorrespondingwiringmustbeinaccordancewiththe

vessel'snationalregistryandcorrespondingmaritimeauthorityand/orclassication

society.

OnlyskilledandauthorizedpersonnelcaninstalltheST90cables.

KongsbergMaritimewillnotacceptanyresponsibilityforerrors,malfunctionsor

damagetosystemorpersonnelcausedbyimproperwiring.

Relatedtopics

InstallingtheST90cables,page171

Cablelayoutandinterconnections
