Orientationofthehullunit

Asageneralrecommendation,thehullunitshallbeorientedwiththehoist/lowermotor

pointingaft

.IfthisorientationmakesitdifculttoaccesstheMotorControlUnit,the

hullunitmayberotatedduringitsinstallationtothemostsuitabledirection.

Thephysicaldistancebetween

theTransceiverUnitandthehull

unitislimitedbythelengthofthe

transducercables.

Note

Irrespectiveofthephysicalhull

unitorientation,thetransducer

shallnot

bemechanicallyaligned.

Hullunitalignmentisdoneinthe

ST90softwarebyrotatingtheecho

presentationinthedisplayview.

Relatedtopics

Sonarroomrequirements,page66

SimradST90InstallationManual
