192

442703/B

ØverlandUPC-3005Technicalspecications

TheØverlandUPC-3005seriallinesplitteroffersoneinputandeightRS-232and

RS-422outputs.

•Powerrequirements:+15-30VDC(2W)

•Input:NMEA0183,RS-232,RS422,

RS484,Currentloop

•Outputs:

–5xRS-422,(Maximum50mA)

–3xRS-232

Alloutputsfromtheseriallinesplitter

areshortcircuitprotected.

•Installation:Theseriallinesplitteris

ttedwithaDINrailforeasymounting

andreplacement.

•Outlinedimensions:

–Length:130mm

–Width:80mm

–Height:50mm

Note

Thisinformationwascopiedfrom

themanufacturer’ sdocumentation.Thetechnicalspecicationsmaybechanged

withoutpriornotice.Toensurethatyourinformationiscorrect,alwaysconsultthe

manufacturer’ sowndocuments.

Relatedtopics

ØverlandUPC-3005Seriallinesplitterdescription,page191

ØverlandUPC-3005Technicalspecications,page192

ØverlandUPC-3005Connections,page193

ØverlandUPC-3005Dimensions,page194
