338
442703/B
12Providetheaccuratephysicallocationofthesensor(oritsantenna)withreference
tothevessel’scoordinatesystem.
ThepositionofcertainsensorsmustbedenedasanoffsettotheShipOrigininthe
coordinatesystemtomaximizeperformance.Theseoffsetvaluesareallrequired
toallowtheST90togiveyouasaccurateinformationaspossible.Thedegreeof
accuracyofferedbytheST90isdirectlyrelatedtotheaccuracyoftheinformation
youenterontheSensorInstallationpage.
aSelecttheoffsetvalueontheXaxis(fore-and-aftdirection)fromtheShip
Origin.AdjustwithapositivevalueforXifthesensorislocatedahead
ofthe
shiporigin.
bSelecttheoffsetvalueontheYaxis(athwartship)fromtheShipOrigin.
AdjustwithapositivevalueforYifthesensorislocatedonthestarboard
sideoftheshiporigin.
cSelecttheoffsetvalueontheZaxis(vertical)fromtheShipOrigin.Adjust
withapositivevalueforZifthesensorislocatedundertheshiporigin.
13SelectAddtosavethenewsensorinterfaceyouhavedened.
ThesensorinterfaceisaddedtotheInstalledSensorslistontheSensorInstallation
page.
14Atthebottomofthedialogbox,selectApplytosaveyoursettings.
15ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Furtherrequirements
OntheleftsideoftheInstallationdialogbox,selectSensorConguration.Denethe
priorityofthedatagrams,andsetuprelevantcongurationparameters.
Relatedtopics
Settingtoworksummary,page242
Settinguptheinterfacestoperipheraldevices,page328
Conguringthesensorinterface
WithseveralsensorsconnectedtotheST90,manyofthemwillprovidethesame
datagrams.Wecannotexpectthatthedatagramsprovidethesameinformation.
TheSensorCongurationpageallowsyoutodeneadatagrampriority,sothatthe
informationfromthe"mostreliable"sensorisusedbytheST90.Youcanalsodene
manualvaluesincaseasensorisunserviceable,ornotinstalled.
Prerequisites
Thisprocedureassumesthat:
ThenewsensorisphysicallyconnectedtotheST90usingaserialornetworkcable.
Theinterfaceportissetupwiththecorrectcommunicationparameters.
