Simrad ST90 Installation Manual

242
442703/B
Settingtoworksummary
Onceallthehardwareunitshavebeeninstalled,andallthecableshavebeenconnected,
theST90canbeturnedonforthersttime,andsettowork.
Prerequisites
BeforeyoucansettheST90towork,thefollowingworkmustbenalized.
•AllST90hardwareunitshavebeeninstalledaccordingtotherelevantinstructions.
•Allsystemcableshavebeeninstalled.
•Allconnectionshavebeenmade.
•Alloperatingpowerisavailable.
•AllperipheraldevicesthatshallcommunicatewiththeST90areavailableand
operational.
•Allrelevantpersonnelandtoolsareavailable.
Context
Someofthesetasksmaybedonewhilethevesselisindrydock.However,weassume
thatthevesselissetaoatbeforeyoustartwiththe"settingtowork"procedures.
Note
YoumustneverstartST90transmissions("pinging")whentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair .Itisthereforeveryimportant
thattheST90systemremainsswitchedoff
whenthevesselisindrydock,andthatno
onetriestouseit.
Procedure
1DoathoroughvisualinspectiontoverifythattheST90isreadyforoperationaluse.
aVerifythatallhardwarehavebeeninstalledcorrectly.
bVerifythatallcableshavebeenconnectedcorrectly.
•InspectingtheST90installation,page245
2Startupthehullunit.
•Startingupthehullunit,page257
3TurnontheST90forthersttime.
•TurningontheST90forthersttime,page276
