Simrad ST90 Installation Manual

478
442703/B
•1:Interferenceisdetected
14SL:Signallevel
ThesignallevelofthetelemetrypulsemeasuredindB//1µPa.
15NL:Noiselevel
TheaveragenoiselevelofthecurrentchannelmeasuredindB//1µPa.
16G:currentgain,0,20or40dB
17Cb:Cablequality
•0:Cableisnotconnected.
•1:CableisOK.
•2:Ashortcircuit,orthehydrophonecurrentistoolarge.
18error:Errordetected
0whennoerrorisdetected.Anumbergreaterthan0indicatesanerrorcondition.
19chksum:Checksum
Thechecksumeldconsistsofa"*"andtwohexdigitsrepresentingtheexclusive
ORofallcharactersbetween,butnotincluding,the"$"and"*"characters.
Note
Thisdatagramformatisobsolete,anditisnolongerinuseonnewdesigns.Ithas
beenreplacedbydatagramPSIMP-D1.
Relatedtopics
Proprietarydatagramformats,page473
SimradPSIMP-Fdatagramformat
SimradPSIMP-FisaproprietarydatagramformatcreatedbyKongsbergMaritime
toprovidethetypeandcongurationofPSandPIsensorsusedbyaSimradcatch
monitoringsystem.
Format
$PSIMP,F,S1,S2,S3,T1,T2,T3,F1,F2,F3*chksum<CR><LF>
Description
Note
Thisdatagramdescriptionisnotcomplete.Ifyouneedfurtherinformation,contact
KongsbergMaritime.
