Simrad ST90 Installation Manual

318
442703/B
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4Selectwhichoperatingpaneltouse.
5UnderUserSettingButtons,assignonepredenedsettingtoeachbuttononthe
operatingpanel.
6Atthebottomofthepage,selectApplytosaveyoursettings.
7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
AssigningfunctionstotherotaryswitchesontheOperating
Panel
TheOperatingPanelisttedwiththreerotaryswitches.Theswitchesareidentiedwith
numbers.Eachswitchcanbeassignedafunctionrelatedtorange,gainorbearing.
Context
TheOperatingPanelpageisusedtoselectwhich
physicalhardwarepanelyouuseonyourST90,and
toassignfunctionalitytotheprogrammablebuttons.
ThispageislocatedintheInstallationdialogbox.The
InstallationdialogboxislocatedontheSetupmenu.
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4Selectwhichoperatingpaneltouse.
5UnderRotarySwitchOptions,assignonefunctiontoeachrotaryswitchonthe
operatingpanel.
6Atthebottomofthepage,selectApplytosaveyoursettings.
SimradST90InstallationManual
