ChoosingthebestlocationfortheProcessorUnit
TheProcessorUnitcanbeinstalledinsideaconsole,insideasuitablecabinet,ina19"
rackoronadesk.Makesurethatadequateventilationisavailabletoavoidoverheating.
ThephysicalpositionoftheProcessorUnitmustbe
chosentottheavailablecablelengthsbetweenthe
computerandtheotherunitsitconnectsto.Makesure
thatenoughspaceismadeavailableformaintenance
purposes.Inordertoallowforfuturemaintenance,we
stronglyadvicethatyoumountthecomputerwithitsrearandfrontpanelsavailablefor
immediateaccess.Observethelimitationsduetothecablelengths.
Compasssafedistance
•Model:ST90ProcessorUnit(Enix)
•Standardcompass:200cm
•Othercompass:140cm
Relatedtopics
Locationofhardwareunitsonthebridge,page62
Systemunits,page408
ChoosingthebestlocationfortheOperatingPanel
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationofthe
ST90.TheOperatingPanelmustbemountedinanearlyhorizontalposition,andwithin
easyviewingrangeofthedisplay.
WerecommendthattheOperatingPanelispositioned
inthesamephysicaldirectionasthedisplay,sothat
"up"ontheoperatingpanelisthesameas"up"onthe
display.Experiencehasshownthatthiswillmakeit
easiertousethetrackballontheoperatingpanelwhen
youwishtocontrolthecursoronthedisplay.
Compasssafedistance
•Makeandmodel:ST90OperatingPanel
•Standardcompass:Notyetavailable
•Othercompass:Notyetavailable
Relatedtopics
Locationofhardwareunitsonthebridge,page62
Systemunits,page408
