Simrad ST90 Installation Manual

202
442703/B
•SynchronizationinFreerunningmode
WheninFreerunningmode,theST90willpingasfastaspossible,settingitsReady
toSend(RTS)signaltoalogic"high"atstartofeachping,andbacktologic"low”
attheendoftheping.The"Slave"systemistriggeredthewhentheReadytoSend
(RTS)signalgoesfrom"low"to"high".
•SynchronizationinWaitforslavemode
WheninWaitforslavemode,theST90willwaitforalogic"high"CleartoSend
(CTS)signalfromthe"Slave"systembeforeitstartsanewpingsequence.Thisisthe
"readytoping"acknowledgefromthe"Slave"system.
Note
IfyouusetheST90as"Master"tocontroltwo"Slave"systems,youmustconnecta
singlecable(plusground)fromtheReadytoSend(RTS)outputontheMastersystemto
theCleartoSend(CTS)inputonboth"Slave"systems.ThereturnfromtheReadyto
Send(RTS)outputsonthe"Slave"systemscannotbeconnected.
Relatedtopics
Cabledrawingsandspecications,page206
SettinguptheST90inasynchronizedsystem,page199
SettinguptheST90inasynchronizedsystem
IfyouwanttousetheST90asamasterorslaveinasynchronizedsystem,youmustset
itupforsuchoperation.Todothis,youmustselectwhichcommunicationporttousefor
thesynchronizationinterface,andyoumustselecttherequestedsynchronizationmode.
Prerequisites
Thisprocedureassumesthat:
•Thevesselisberthedoratsea.
•YouhaveanRS2-232interfaceportonyourProcessorUnitthatallowsyoutousethe
CTS/RTSconnections.
For"slave"operation,aremotesystem(forexampleK-SyncorSimradTU40)mustbe
availabletoprovidetriggerpulses.For"master"operation,aremotehydroacoustic
system(sonar,echosounder)isconnected.Thisremotesystemmustbesetupin"slave"
mode.
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe
normaltoolsforelectronicandelectromechanicaltasks.Thisincludesdifferent
screwdrivertypes,pliers,spanners,acablestripper,asolderingiron,etc.Eachtool
mustbeprovidedinvarioussizes.Werecommendthatalltoolsaredemagnetizedto
protectyourequipment.
SimradST90InstallationManual
