Simrad ST90 Installation Manual

442703/B
473
Proprietarydatagramformats
Topics
KongsbergDFTWaterleveldatagramformat,page473
KongsbergOFSDropkeeldatagramformat,page474
SimradATSdatagramformat,page474
SimradDBSdatagramformat,page475
SimradHFBdatagramformat,page475
SimradPSIMDHBdatagramformat,page476
SimradPSIMP-Ddatagramformat,page476
SimradPSIMP-Fdatagramformat,page478
SimradTDSdatagramformat,page479
SimradTPRdatagramformat,page480
SimradTPTdatagramformat,page480
Teledyne/TSS1datagramformat,page481
KongsbergEMAttitude3000datagramformat,page483
KongsbergDFTWaterleveldatagramformat
TheproprietaryDFTdatagramcontainsthecurrentwaterlevel(draft).Theinformation
isrequiredtoestablishtheoffsetofthetransducerfacerelativetothevesselorigin.A
custom-builtsensormayberequiredforthismeasurement.
Format
$KMDFT,xx.xx,*hh
Description
Thedepthismeasuredrelativetothevessel’sorigin.
•KM:Talkeridentier
•DFT:Datagramidentier
•xx.xx:Waterlevelinmetres
•*hh:Checksum
Relatedtopics
Proprietarydatagramformats,page473
Datagramformats
