ØverlandUPC-3005Seriallinesplitterdescription

TheØverlandUPC-3005isaseriallinesplitterwithoneinputandeightoutputs.

UPC3005isaseriallinesplitterwith1signalinput,

3xRS-232and5xRS-422outputs.

Thepowersupplyandbothsignalinputsaregalvanic

isolatedfromtheoutputs.

AlloutputsareShortCircuitProtected.

Informationfromthemanufacturer’ swebsite,copied

January2017

TheseriallinesplitteristtedwithaDINrailforeasy

mountingandreplacement.

Note

Theseriallinesplitterrequiresadedicatedpowersupply

providing15to30VDC.

Formoreinformationaboutthisseriallinesplitter,consultthemanufacturer’swebsite.

•Manufacturer:Øverland

•Manufacturer’swebsite:http://www.overland.no

Relatedtopics

ØverlandUPC-3005Seriallinesplitterdescription,page191

ØverlandUPC-3005Technicalspecications,page192

ØverlandUPC-3005Connections,page193

ØverlandUPC-3005Dimensions,page194

Aboutseriallinesplitters,page190
