Simrad ST90 Installation Manual

442703/B
475
SimradDBSdatagramformat
SimradDBSisaproprietarydatagramformatcreatedbyKongsbergMaritimetoprovide
thecurrentdepthofthetrawlsensor.
Format
@IIDBS,,,x.x,M,,<CR><LF>
Description
1II:Talkeridentier
2DBS:Datagramidentier
3x.x,M:Depthinmetres(0–2000)
Relatedtopics
Proprietarydatagramformats,page473
SimradHFBdatagramformat
SimradHFBisaproprietarydatagramformatcreatedbyKongsbergMaritime.It
providestheverticaldistance(height)fromtheheadropetothefootrope,andfromthe
headropetothebottom.TheheightsaremeasuredbyanITITrawlEyeoraheightsensor.
Format
@IIHFB,x.x,M,y.y,M<CR><LF>
Description
1II:Talkeridentier
2HFB:Datagramidentier
3x.x,M:Thisisthedistance(height)fromtheheadropetothefootrope.(0–100m)
4y.y,M:Thisisthedistance(height)fromheadropetobottom(seabed).(0–100m)
Tip
Ifyouusetwoheightsensors,theinformationfromthesecondsensorisprovidedinthe
SimradHB2datagram.
Relatedtopics
Proprietarydatagramformats,page473
Datagramformats
