Simrad ST90 Installation Manual

442703/B
103
2Lowerthegatevalvedownintothehullunitcompartment,butstopwhentheunitis
afewcentimetresabovethemountingange.
Note
Donotdamagethematingsurfacesonthevalve,theendswitches,or(ifrelevant)
thehydraulicactuator.
3Verifythatthematingsurfaceonthevalveiscleanandundamaged.
4Preparethemountingange.
aRemovetheprotectivecoverfromthematingsurfaceonthemountingange.
bVerifythatthematingsurfaceonthemountingangeiscleanandundamaged.
cWipeathinlmofsiliconegreaseontheO-ringandplaceitinthegrooveon
themountingange.
5Attachthenutsandwasherswhilethegatevalveisstillsuspended.
Duetothelimitedspace,itmaybedifculttoenterand/ortightensomeofthenuts.
AnalternativeisthentouseLoctite270orsimilar.
6Lubricatethethreadswithahighgradecommercialanti-seizelubricant.
7Lowerthevalvecarefullyontothemountingangewhiletighteningthenuts.
8Verifythatthevalveisorientatedandalignedcorrectly.
9Disconnectandremovethetacklesfromthegatevalve.
10Tightenthenutstotorque472Nm.
Relatedtopics
InstallingtheoptionalgatevalveDN500,page85
Gatevalveinstallationoverview,page86
083045GatevalveinstallationDN500,page449
33498GatevalvedimensionsDN500,page451
37357GatevalvedimensionsDN500,page454
Installingthetransducerdock
Thetransducerdockismountedonthetopofthegatevalve.Thetopmatingsurface
isinparallelwiththeseasurfaceduringnormaloperatingconditions.Thetransducer
dockprotectsthetransducerwhentheST90isnotused.
Prerequisites
Thistaskmusttakeplaceindrydock.Theshipyardmustprovideallnecessarytoolsand
manpower.Thefollowingspecicitemsarerequiredforthistask.
•Siliconegrease
InstallingtheoptionalgatevalveDN500
