442703/B

467

NMEAHDMdatagramformat

TheNMEAHDMdatagramprovidesvesselheadingindegreesmagnetic.Thedatagram

formatisnolongerrecommendedforuseinnewdesigns.Itisoftenreplacedbythe

NMEAHDGtelegram.

Format

$--HDM,x.x,M*hh<CR><LF>

Description

1$—:Talkeridentier

2HDM:Datagramidentier

3x.x,M:Heading(DegreesMagnetic

4*hh:Checksum

Relatedtopics

NMEAdatagramformats,page461

NMEAHDTdatagramformat

TheNMEAHDTdatagramprovidesthetruevesselheading.Theinformationis

normallyprovidedbyacoursegyro.

Format

$--HDT,x.x,T*hh<CR><LF>

Description

1$—:Talkeridentier

2HDT:Datagramidentier

3x.x,T:Heading(DegreesTrue)

4*hh:Checksum

Relatedtopics

NMEAdatagramformats,page461

Datagramformats
