Simrad ST90 - Checking the Transducer Lowering and Hoisting Functionality

442703/B
273
Checkingthetransducerloweringandhoistingfunctionality
Duringnormaloperation,thetransducerisloweredandhoistedfromtheOperating
Panel.Duringthisfunctionaltest,however,theoperationiscontrolledfromtheMotor
ControlUnit.
Prerequisites
Beforeyoucandothistask,the
followingprerequisitesmustbemet:
•TheST90isturnedoff.
•Thecircuitbreakerforthe3-phase
ACpowerisclosed.ACpower
isconnected.
•Thetransducerisinitsupper
positionwiththeUpperLimit
Switch(S304)activated.
Youmustbeequippedwitha
standardsetoftools.Thistoolset
mustcomprisethenormaltoolsfor
electronicandelectromechanical
tasks.Eachtoolmustbeprovided
invarioussizes.Werecommendthat
alltoolsaredemagnetizedtoprotect
yourequipment.
Context
Thistaskservestwopurposes.
•Youwillverifythatthetransducercanbeloweredandhoistedwithlocalcontrol.
•Youwillndthebestwaytosecurethetransducercablesothatitmovesfreelyduring
loweringandhoisting.
WARNING
Highvoltagesareused.Thisequipmentmustbeservicedonlybyqualied
personnelfamiliarwithhigh-voltageequipmentandthepotentialhazards
involved.Failuretoobservethisprecautioncouldresultinbodilyinjury.
Procedure
1Makesurethatyouhavesufcientwaterdepthbelowthekeelbeforeyoulower
thetransducer.
2LocatethehandcrankinsidetheMotorControlUnit.Removethehandcrank
fromitsstorageposition.
Settingtowork
