NMEAdatagramformats

Topics

NMEADBSdatagram,page461

NMEADBTdatagram,page462

NMEADPTdatagram,page463

NMEAGGAdatagramformat,page463

NMEAGGKdatagramformat,page464

NMEAGLLdatagramformat,page465

NMEAHDGdatagramformat,page466

NMEAHDMdatagramformat,page467

NMEAHDTdatagramformat,page467

NMEARMCdatagramformat,page468

NMEAVBWdatagramformat,page469

NMEAVHWdatagramformat,page470

NMEAVLWdatagramformat,page470

NMEAVTGdatagramformat,page471

NMEAZDAdatagramformat,page471

NMEADBSdatagram

TheNMEADBSdatagramprovidesthecurrentdepthfromthesurface.Thedatagram

isnolongerrecommendedforuseinnewdesigns.Itisfrequentlyreplacedbythe

NMEADPTdatagram.

Format

$--DBS,x.x,f,y.y,M,z.z,F*hh<CR><LF>

Description

Alldepthsaremeasuredfrombelowtheseasurface.

1$—:Talkeridentier

2DBS:Datagramidentier

3x.x,f:Depthinfeet

4y.y,M:Depthinmetres

Datagramformats
