Aboutinstallationdrawings
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Note
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationofthe
ST90mustbeapprovedbythevessel’ snationalregistryandcorrespondingmaritime
authorityand/orclassicationsociety.Suchapprovalmustbeobtainedbeforethe
installationcanbegin.Theshipownerandshipyarddoingtheinstallationareresponsible
forobtainingandpayingforsuchapproval.
KongsbergMaritimeoffersfreeadviceforinstallationplanning.Proposedarrangements
maybesentforcommentaryorsuggestions.Thefollowingdrawingsshouldbe
submittedshouldassistanceberequested:
•Generalarrangement
•Bodyplananddrawingsoftherelevantcompartment
•Linesplan
Relevantoutlinedimensionsandproductiondrawingscanbedownloadfromour
website.MostdocumentsareavailableinPDFand/orAutoCad(DWG)formats.
•https://www.simrad.com
Relatedtopics
Installationsummary,page54
Tools,equipmentandconsumablesrequired
forST90installation
InordertodotheST90installation,allnecessarytoolsandequipmentformechanical
work,cabinetinstallationandelectricalwiringmustbeavailable.
Itisnotpracticaltoprovideadetailedlistofallnecessarytoolsandequipment.Youmust
beequippedwithastandardsetoftools.Thistoolsetmustcomprisethenormaltools
forelectronicandelectromechanicaltasks.Thisincludesdifferentscrewdrivertypes,
pliers,spanners,acablestripper,asolderingiron,etc.Eachtoolmustbeprovidedin
varioussizes.Werecommendthatalltoolsaredemagnetizedtoprotectyourequipment.
However,youmustmakesurethatthefollowingspecializedtoolsareavailable.
•Allnecessarytoolsandconsumablesrequiredforwelding
•Allnecessarytoolsandconsumablesrequiredforphysicalinstallationofunits,
cabinetsandracks
•Allnecessarytoolsandconsumablesrequiredforelectricalinstallations
