Mountingangeandmanualgatevalveinstallation

Thisillustrationdemonstratesthemountingprinciplesforamanualgatevalve.The

mountingangeandthegatevalveareshown.Thedrawingsarenottoscale.

AFrames

BKnee-plates(stiffeners)

CGatevalve

AKnee-plates(stiffeners)

BShellplating

CAsshortapossible

DO-ring

EMountingbolts/Nuts/Washers

FMakesurethattheelectricalconnectionstotheendswitchesareeasilyaccessible.

InstallingtheoptionalgatevalveDN500
