Simrad ST90 Installation Manual

184
442703/B
ProcessorUnitserialadapter
Topics
ProcessorUnitserialadapter,page184
RS-485seriallineconnectionusingtwoorfourwires,page186
MoxaCP114EL-ISeriallineadapter,page187
SettinguptheMoxaCP114EL-Iserialports,page188
ProcessorUnitserialadapter
TheMoxaCP114EL-IadapterisusedintheST90ProcessorUnittoprovideserial
communication.Theboardprovidesfourseriallines.Theseriallinesareconnected
usingalargeD-SubminiatureconnectorontherearsideoftheProcessorUnit.
TheMoxaCP114EL-IserialadaptersupportsRS-232,
RS-422andRS-485(both2and4-wire).The
connectionstotheboardaremadeusingaconverter
cablewithfour9-pinmaleD-subminiatureconnectors.
TheconvertercableissuppliedwiththeProcessorUnit.
•Manufacturer:Moxa
•Manufacturer’swebsite:https://www.moxa.com
Adapter
Adedicatedadaptercableis
providedwiththeST90delivery.
Theadaptersplitsthelargecircuit
boardconnectortofour9-pin
D-Subminiatureconnectors.Tomake
theindividualconnectionseasier,
9-pinD-Subminiatureconnectors
withscrewterminalsareincluded
inthedelivery.Nutstoestablishrm
connectionsarealsoprovided.
Seriallinesupport
Theserialadaptersupportsthefollowinginterfaceformats.
•Port1:RS-232/RS-422/RS-485
•Port2:RS-232/RS-422/RS-485
•Port3:RS-232/RS-422/RS-485
