442703/B

213

RS-232usedassynchronizationtrigger(inputoroutput)

AnRS-232seriallineconnectionusingtheRequestToSend(RTS)andClearTo

Send(CTS)signalsiscommonwaytoconnecttheST90toexternaldevicesfor

synchronizationpurposes.

ALocalconnection

BConnectiononremotedevice

CFemale9-pinD-Subminiatureconnector

DMale9-pinD-Subminiatureconnector

ThiscabletakesthecontrolsignalsonaRS-232serial

line,andusestheseasanexternaltrigger.Itprovides

interfacewithanyperipheralunitthatrequiresorcontrols

transmit/receivesynchronization.Notethatthiscable

doesnotsupportallthesignalsinthestandardRS-232specication.

Note

ThissynchronizationmethodcanonlybeusedwithRS-232communication.Youcan

onlyconnecttwosystemstogether .

Unlessotherwisespecied,thiscablemustbeprovidedbytheinstallationshipyard.

Minimumcablerequirements

•Conductors:2x4x0.5mm

•Screen:Overallbraided

•Voltage:60V

•Maximumouterdiameter:Denedbytheplugsand/orthecablegland

Ifyouneedtoinstallaverylongcable,increasethecrosssection.

Relatedtopics

Aboutseriallines,page230

Cabledrawingsandspecications,page206

Cablelayoutandinterconnections
