OperatingPaneldescription
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationofthe
ST90.
ThecontrolsprovidedbytheOperatingPanelare
arrangedinlogicalfunctionalgroups.Thisoffers
youclearandeasyoperationwithfastaccesstokey
functionality.ThemajorityoftheST90functionscan
beaccessedusingthetrackballontheOperatingPanel
andthemenusystemshownintheST90presentation.
Tip
YoucanalsouseastandardcomputermousetocontroltheST90.Themousecanbe
connectedtoeithertheOperatingPanelordirectlytotheProcessorUnit.
AdedicatedEthernetcableisusedtoconnecttheOperatingPaneltotheProcessorUnit.
TheOperatingPanelisprovidedwithabuilt-inpowersupply.Themainsvoltageforthe
OperatingPanelis115or230V AC,anditwillautomaticallysensethesupplyvoltage.
Note
TheST90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and
"Mk2".
AsecondaryOperatingPanelmaybeconnectedtotheST90ProcessorUnit.Thismay
beusefulinconjunctionwithaseconddisplayifyouwishtocontroltheST90fromtwo
differentlocationsonyourvessel.
Relatedtopics
Systemunits,page23
Scopeofsupply,page32
InstallingtheOperatingPanel(Mk2),page151
Technicalspecications,page388
SettinguptheOperatingPanel(Mk2),page278
UsingasingleOperatingPaneltocontrolmorethanonesonar(Mk2),page320
UsingmorethanoneOperatingPaneltocontrolthesonar(Mk2),page324
204688OperatingPaneldimensions(Mk1),page413
440698OperatingPanelcut-outdrawing(Mk2),page415
443179OperatingPaneldimensions(Mk2),page416
439594OperatingPaneladapterplate(Mk2),page419
