Simrad ST90 Installation Manual

494
442703/B
6Oncethecartonisopen,carefullyremoveallloosepackingandinsulationmaterial.
7Checkforusermanualsandotherdocumentsthatmayhavebeenaddedtothe
cartonduringpacking.
8Checkalsoforspecialtools,doorkeysetc.
Relatedtopics
Unpackingmechanicalunits,page494
Unpackingelectronicandelectromechanicalunits,page495
Unpackingmechanicalunits
Priortoinstallationoruse,mechanicalunitsmustbeunpackedfromtheirtransportboxes.
Itisimportantthatthisunpackingisdonewithoutinictingdamagetotheequipment.
Prerequisites
Observetheprocedureforunpackingofstandardpartsandunits.
Context
Mechanicalandelectromechanicalunitsmaybeheavy.
Hullunitsprovidedforsonarsystemsareprovidedwiththetransduceralreadymounted.
Note
Thetransducerisadelicateitem.Makesurethatitisnotexposedtophysicaldamage
duringthestorage,unpacking,liftingandinstallationofthehullunit.Thetransduceris
protectedwithaboxshapedfoam.Donotremovethisprotectionuntilthenalstagesof
thehullunitinstallation.
Atransducermustalwaysbehandledasadelicateinstrument.Incorrectactionsmay
damagethetransducerbeyondrepair.
Observethesetransducerhandlingrules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donothandlethetransducerroughlyandavoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotusehigh-pressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducerface.
•Donotdamagetheouterprotectiveskinofthetransducer.
Procedure
1Obtainthenecessaryliftingequipment,andmakesurethattheequipmentis
certiedfortheweight.
2Lifttheunitoutofthetransportationbox.
SimradST90InstallationManual
