180

442703/B

TransceiverUnitconnectors

AllsocketsforthesystemcablesarelocatedatthebottomoftheTransceiverUnit.

Thetransducercablesarepluggedintothesidewallofthetransceivercabinetusinga

specialconnector.

ANotused

BEthernetcable:FromTransceiverUnittoProcessorUnit(C8)

CEthernetcable:FromTransceiverUnittoProcessorUnit(C8)

DEthernetcable:FromTransceiverUnittoMotorControlUnit(C26)

EACpowercable:FromTransceiverUnittouninterruptiblepowersupply(UPS)

(C22)

FFuses

Note

DONOTconnectthetransceiverplugtothesocketontheTransceiverUnit.This

connectionismadeasapartoftheSettingtoworkprocedures.

Itisveryimportantthathigh-qualityEthernetcablesareused.YoumustuseCAT-5E

STP(ShieldedTwistedPair)qualityorbetter .Ifyouusecableswithlowerbandwidth

capacityyouwillreducetheST90performance.Donot

connecttheProcessorUnitto

theTransceiverUnitusinganexistinglocalareanetwork(LAN).

Relatedtopics

InstallingtheST90cables,page171

InstallingtheST90sonarroomcables,page175
