Simrad ST90 Installation Manual

32
442703/B
Scopeofsupply
Topics
Basicitemsprovidedwithastandarddelivery,page32
Additionalrequireditems,page35
Additionaloptionalitems,page39
Basicitemsprovidedwithastandarddelivery
ToassembleacompleteST90system,youwillneedasetofsystemunits.Themain
unitsrequiredareprovidedwiththestandarddelivery.Otherrequiredunitsmaybe
purchasedfromKongsbergMaritimeorobtainedlocally.Someunitsareoptional.
WhenyouunpackthepartsprovidedwiththeST90delivery,makesurethatthecorrect
itemsareincluded.
Basicitems
ItemPartnumberInthebox
TransceiverUnit
441481
TransceiverUnit
Powercable
Ethernetcable(10m)
ProcessorUnit
441484Computer
Powercable
Seriallineconnectorsandadapters
DVItoVGAadapter
Documentation
Software
PhoenixContact"V ariosubRJ45
Quickcon"connectorx2
OperatingPanel(Mk1)
SH8-203593
OperatingPanel
Interfacecables
Mountinghardware
OperatingPanel(Mk2)
442453
OperatingPanel
Ethernetcable
Mountinghardware
Connectioncable
329512
Ethernetcable(100m)
TheST90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and"Mk2".
HullUnit
TheST90Fishndingsonarcanbeprovidedwithoneofthefollowinghullunits.The
sametransducerisusedonallhullunittypes.Thesameinstallationtrunkisusedon
allhullunittypes.
SimradST90InstallationManual
