286
4 Adjusting knitting machine
Working with the Sintral editor
"Auto-Sintral" function key To activate this key, "Auto-Sintral" must be loaded. In the editor now one can
switch between the currently loaded pattern and "Auto-Sintral".
Auto-Sintral k ey
"Auto-Sintral" key
"Tile window horizontally"
function key
This function makes two editors available which work independently of one
another. When opening, the jacquard is jumped to in the lower editor. The size
of the division is changed via both arrow keys on the left or right sides at the
bottom edge of the screen.
Window for the function Tile wi ndow horiz ontally
Window for the function "Tile window horizontally"
Function keys for th e function Tile window horizon tally
Function keys for the function "Tile window horizontally"
Key
Function
Switch over between current pattern and "Auto-Sintral"
Key
Function
Key
Function
enlarge lower part
enlarge upper part
