314

5 Setup Data

Setup2 Editor

The Input Helper for Yarn

Carriers (YLC tab)

Element Function

Enter yarn carrier specification

Example: 3A

Delete entry

Move cursor: one character to left

Move cursor: one character to the right

Confirm input
