365
Maintenance of the knitting machine 6
Lubricate knitting machine
Central lubri cation windo w
"Central lubrication" window
Field
Explanation
1
Switch on/off the central lubrication.
Switch off the central lubrication: Observe the section "Switch off
Central Lubrication" [366]
!
2
Three settings are available for the lubrication interval:
Initial lubrication: This setting is used for the initial lubrication of a
new machine at the Stoll stoll factory. The values cannot be
modified. (Caution - risk of soiling the fabric)
Select this setting for approx. 15 minutes after a gauge conversion
or with a machine, which has been out of operation for a longer
period of time.
STOLL inputs: This setting can be used for production. The values
cannot be modified. The values cannot be modified.
User settings: With this setting, the values can be changed by the
user. (Attention: An improper setting could lead to insufficient oiling.
Ensure that the central lubrication applies sufficient oil to the needle
bed.)
3
Each setting consists of two values.
Lubricat. process after system run-throughs:
Setting of the number of knitting systems after which lubrication
occurs. The lubrication procedure stretches across the current
traversing path of the carriage.
Lubrication processes until lubricating all needles:
Setting of the number of lubrication procedures after which the entire
needle bed is to be lubricated.
4
Number of system run-throughs since the last lubrication process
5
A lubrication procedure is triggered in the next carriage reversal.
The entire needle bed is lubricated.
6
The oil line is de-aerated with this switch. The oil pump is switched
on for max. 30 seconds. Use this switch for ventilation only, not for
lubrication (Caution - risk of soiling the fabric).
All lubrication processes and operating actions are logged. The
inputs can be read. For this purpose, call up the "additional
function keys" and the "Central lubrication log" key in the
"Central lubrication" window.
