389
Repairing the knitting machine 7
Replacing parts
Type 3
To replace the intermediate slider, you need a small pair of pliers.
Replacing the intermediate slider
Replacing the intermediate slider
1. Push the needle and coupling part (1) upward.
2. Push the spring wedge (3) to the side.
3. Pull out the intermediate slider (2) upwards.
4. Install the new intermediate slider in the reverse order.
5. Slide the needle and coupling pa
rt into the home po
sition.
Valid for:
CMS 830 C, CMS 520 C
all gauges
