411
Repairing the knitting machine 7
Replacing parts
12. Push away the carriage assembly.
13. Lift the carriage part off the support surface.
- or -
➜ Open the side safety door hood and lift out
the carriage part to the side.
14. To replace the cams, turn the cam plate upward.
Further information:
Switching power supply 40 V off and on [375]
Central lubrication - mounting
and working position [377]
Removing cam plate [419]
If the carriage assembly is blocked:
The drive brake has automatically closed.
➜ Release the drive brake again and continue
pushing the
carriage assembly in the original direction.
