Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
CURSor:VBArs:DELTa? Returns the difference between vbar cursors
CURSor:VBArs:POSITION<x> Sets or returns the vbar cursor<x> horizontal
position
CURSor:VBArs:POS<x> Sets or queries the horizontal position for
vertical ba
rcursors
CURSor:VBA
rs:UNIts
Sets or r etu
rns the units for vbar cursors
CURSor:WA
VEform
Sets or ret
urns the current settings for
waveform cursors
CURSor:WAVEform:HDELTA ? Returns the horizontal difference between
waveform cursors
CURSor:WAVEform:HPOS<x>? Returns the position of waveform cursor <x>
CURSor:WAVEform:POSition<x> Sets or returns the position of w aveform
cursor
<x>
CURSor
:WAVEform:STYle
Sets or
returns the cursor type for waveform
mode
CURSor:WAVEform:UNIts Sets or r eturns the units for waveform cursors
CURSor:WAVEform:VDELTA? Returns the vertical difference between
waveform cursors
CURSor:XY? Returns the current settings for XY cursors
CURSor:XY:PRODDE Lta? Returns the product of the difference
bet
ween the cursors X positions and Y
positions
CURSor:XY:PRODUCT<x>? Returns the product of the X and Y positions
for the specified cursor
CURSor:XY:RADIUS<x>? Returns the radius of the specified cursor
CURSor:XY:RATDELta? Returns ratio of the difference between the
c
ursors X position and Y position
CURSor:XY:RATIO<x>? Returns ratio of the X (horizontal) and Y
(vertical) position for the specified cursor
CURSor:XY:RDELta?
Returns the Dr value
CURSor:XY:READOUT Sets or returns the XY cursor readout mode
CURSor:XY:RECTX<x> Sets or returns the X cursor position in
rectangular coordinates
CURSor:XY:RECTY<x> Sets or returns the Y cursor position in
rectangular coordinates
CURSor:XY:THDELta?
Returns the XY cursor angle delta in polar
coordinates
CURSor:XY:THETA<x>?
Returns the XY cursor angle in polar
coordinates
CURSor:XY:XDELta?
Returns the XY cursor ΔX value in
rectangular coordinates
CURSor:XY:YDELta?
Returns the XY cursor ΔY value in
rectangular coordinates
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-15
