Command Groups
Command
Description
MASK:SEG<m>:NR_Pt? Returns the number of points that make up
the specified mask segment of the C urrent
mask
MASK:SEG<m>
:POINTS
Sets or retur
ns the X-Y user coordinates of
all points in the Current mask segment
MASK:SOUrce Sets or reports which source will be
compared against the mask(s) when
counting is
turned on
MASK:STAN
dard
Deletes the existing mask and s ets the
selected s
tandard mask
MASK:STO
POnviolation
Sets or re
turns the stop on violation setting
MASK:TES
t:AUX:COMPLetion
Sets or re
turns the test:aux on pass/fail test
completion mode
MASK:TESt:AUX:FAILure Sets o r returns the test:aux status on
pass/fail test failure m ode
MASK:TESt:BEEP:COMPLetion Sets or returns the beep on pass/fail test
comple
tion mode
MASK:
TESt:BEEP:FAILure
Sets o
r returns the beep status on pass/fail
test failure mode
MASK:TESt:DELay Sets or returns the amount of time, in
seconds, to w ait after starting pass/fail
test
ing to evaluate waveforms
MASK
:TESt:HARDCopy
Sets
or returns the hard c opy in pass/fail
failure mode
MASK:TESt:LOG:FAILure Sets or returns the log status on pass/fail
test failure mode
MASK:TESt:REPeat Sets or returns the repeat pass/fail test on
co
mpletion mode
M
ASK:TESt:SAMple
S
ets or returns the minimum number of
waveform database (WfmDB) points the
instrument can acquire before it stops a
s
ingle sequence acquisition or stops running
a mask test
MASK:TESt:SAMple:THReshold Sets or returns the minimum number of hits in
mask regions needed to cause the pass/fail
status to change from PASSING to FAILING
MASK:TESt:SAVEWFM Sets or returns the save waveform to file on
failure setting
MASK:TESt:SAVEWFM:FILEName Sets or returns the name of the directory and
file to use with the MASK:TE St:SAVEWFM
command
MASK:TESt:SRQ:CO MPLetion Sets or returns an SRQ on pass/fail test
completion mode
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-35
