Command Groups
Command
Description
MASK:TESt:SRQ :FAILure Sets or returns the SRQ status on pass/fail
test failure mode
MASK:TESt:STATE Sets or returns the state of mask pass/fail
testing
MASK:TESt:
STATUS?
Returns the
pass/fail test status
MASK:TESt:
STOP:FAILure
Sets or retu
rns the stop status on pass/fail
test failure mode
MASK:TESt:THReshold Sets or returns the number of failed tested
waveforms needed in each pass/fail test to
cause the
pass/fail status to change from
PASSING to FAILING
MASK:TESt:WAVEform Sets or returns the number of waveforms to
test during pass/fail testing
MASK:USER:AMPlitude Sets or returns the current mask’s nominal
pulse am
plitude in volts
MASK:U
SER:BITRate
Sets or
returns the user mask’s bit rate
MASK:
USER:HSCAle
Sets o
r returns the nominal timing resolution
used to draw the mask, in time/division
MASK:USER:HTRIGPOS Sets or returns the nominal trigger position
(pulse leading edge) used to draw the mask
as a f
raction of the display width
MASK
:USER:LABel
Sets
or returns the label assigned to a user
mask
MASK:USER:PATTERNBITS Sets or returns the number of bits used for
serial trigger for the User mask standard
MASK:USER:PRES AMPBITS Sets or returns the number of bits before
th
e (isolated one) pulse leading edge in the
serial trigger pass/fail testing
MASK:USER:RECOrdlength Sets or returns the nominal record length for
pulse m a s k testing
MASK:USER:SEG<m> Deletes the specified mask segment from
the User mas k
MASK:USER:SEG<m>:NR_Pt? Returns the number of points that make up
the specified User mask segment
MASK:USER:SEG<m>:POINTS Sets or returns the X-Y user coordinates of
all points in the specified User mask segment
MASK:USER:TRIGTOSAMP Sets or returns the time, in seconds, from the
(leading edge) trigger position to the pulse
bit sampling position
MASK:USER:VOFFSet Sets or returns the nominal vertical offset,
in volts, used to vertically offset the input
channels
2-36 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
