Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:POLarity:REF<x>
Sets or returns the polarity setting for a
transition trigger search to determine where
to place a mark
. <x> is the search number
or reference waveform number
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:THReshold:HIGH:CH<x>
Sets or returns the threshold high voltage
level setting for a transition trigger search to
determine w
here to place a mark. <x> is the
search number or channel number
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:THReshold:HIGH:MATH<x>
Sets or returns the threshold high voltage
level setting for a transition trigger search to
determine
where to place a mark. <x> is the
search number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:THReshold:HIGH:REF<x>
Sets or returns the threshold high voltage
level setting for a transition trigger search
to determ
inewheretoplaceamark.<x>is
the search number or reference waveform
number
SEARCH:SEARCH<x>:TRIGger:A:
TRANsi
tion:THReshold:LOW:CH<x>
Sets or returns the threshold low voltage
level s
etting for a transition trigger search to
determine where to place a mark. <x> is the
search number or channel number
SEARCH:SEARCH<x>:TRIGger:A:
TRANs
ition:THReshold:LOW:MATH<x>
Sets or returns the threshold low voltage
level
setting for a transition trigger search to
determine where to place a mark. <x> is the
search number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:
TRAN
sition:THReshold:LOW:REF<x>
Sets or returns the threshold low voltage
leve
l setting for a transition trigger search
to determine where to place a mark. <x> is
the search number or reference waveform
numb
er
SEA
RCH:SEARCH<x>:TRIGger:A:
TRANsition:WHEn
Set
s or returns the condition setting for a
transition trigger search to determine where
to place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:TYPe Sets or returns the trigger type setting for a
se
arch to determine where to place a mark.
<x> is the search number
NOTE. Except EDGE all other
options must be purchased.
SEARCH:SEARC H<x >:T R IGger:A:WIDth:
HIGHLimit
Sets or r eturns the upper time limit setting
for a width search to determine where to
place a mark. <x> is the search number
SEARCH:SEARC H<x >:T R IGger:A:WIDth:
LOWLim it
Sets or returns the lower time limit setting for
a width search to determine where to place
a mark. <x> is the search number
2-52 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
