Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:WIDth:
POLarity:CH<x>
Sets or returns the polarity for a width search
to determine where to place a mark. <x> is
the search num
ber or channel number
SEARCH:SEAR
CH<x>:TRIGger:A:WIDth:
POLarity:MATH<x>
Sets or retur
ns the polarity for a width search
to determine where to place a mark. <x>
is the search number or math waveform
number
SEARCH:SEA
RCH<x>:TRIGger:A:WIDth:
POLarity:REF<x>
Sets or retu
rns the polarity for a width search
to determine where to place a mark. <x> is
the search number or reference waveform
number
SEARCH:S
EARCH<x>:TRIGger:A:WIDth:
WHEn
Sets or qu
eries the width search to determine
wheretoplaceamark.
<x> is the search
number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
EVENT
Sets or queries the window search to
determi
ne where to place a mark.
<x> is
the search number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:HIGH:CH<x>
Sets or returns the channel waveform
threshold HIGH level for a window search to
determ
ine where to place a mark. <x> is the
search number or channel number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:HIGH:MATH<x>
Sets or returns the channel waveform
threshold HIGH level for a window search to
deter
mine where to place a mark. <x> is the
search number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:HIGH:REF<x>
Sets or returns the channel waveform
threshold HIGH level for a window search to
dete
rmine where to place a mark. <x> is the
search number or reference number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:LOW:CH<x>
Sets or returns the channel waveform
threshold LOW level for a window search to
de
termine where to place a mark. <x> is the
search number or channel number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:LOW:MATH<x>
Sets or returns the channel waveform
threshold LOW level for a window search to
d
etermine where to place a mark. <x> is the
search number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
THReshold:LOW:REF<x>
Sets or returns the channel waveform
threshold LOW level for a window search
to determine where to place a mark. <x> is
the search number or reference waveform
number
SEARCH:SEARCH<x>:TRIGger:A:WINdow:
WIDth
Sets or returns the width setting for a window
search to determine where to place a mark.
<x> is the search number
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-53
