Status and Events
Table 3-8: Exec
ution Warning Messages (EXE Bit 4)
Code Message
540 Measurement w
arning
541 Measurement warning, Low signal amplitude
542 Measurement warning, Unstable histogram
543 Measurement
warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid min max
546 Measuremen
t warning, Need 3 edges
547
Measureme
nt warning, Clipping positive/negative
548
Measurem
ent warning, Clipping positive
549
Measurem
ent warning, Clipping negative
551
FASTAcq
mode is active – deactivate to use math
Internal Warning. The following table shows internal errors that indicate an
internal fault in the instrument.
Table
3-9: Internal Warning Messages
Code Message
600 Inte
rnal warning
630
Inte
rnal warning, 50 Ω overload
3-16 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
