Tektronix DPO70000 Series Programmer's Manual

Status and Events
Ta ble 3-5: Execution Error Messages (EXE Bit 4 ) (cont.)
Code Message
2411
Syntax error in math string
2412
Semantic error in math string
2413 Math expression is too complex
2420
Histogram cannot be performed on this type of waveform
Device Error. The following table lists the device errors that can occur during
instrument operation. These errors may indicate that the instrument needs repair.
Ta ble 3-6: Device Error Messages (DDE Bit 3)
Code Message
300
Device-specificerror
310
System error
311 Memory error
312 PUD memory lost
313
Calibration memory lost
314
Save/recall memory lost
315
Configuration memory lost
350
Queue overflow (does not set DDE bit)
System Event. The following table lists the system event messages. These
messages are generated whenever certain system conditions occur.
Table 3-7: System Event Messages
Code Message
400
Query event
401
Power on (PON bit 7 set)
402
Operation complete (OPC bit 0 set)
403
User request (URQ bit 6 s et)
404
Powerfail(DDEbit3set)
405 Request control
410
Query INTERRUPTED (QYE bit 2 set)
420
Query UNTERMINATED (QYE bit 2 set)
430
Query DEADLOCKED (QYE bit 2 set)
440
Query UNTERMINATED after indefinite response (QYE bit 2 set)
Execution Warning. The following table lists warning messages that do not
interrupt the flow of command execution. These notify you that you may get
unexpected results.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 3-15
