Tektronix DPO70000 Series Programmer's Manual

Appendix C: Factory Default Setup Values
Command Default Values
HORizontal:MODE:SAMPLERate ≥12.5 GHz instruments: 50 GS/s
≥3.5 GHz and ≤8 GHz instruments:
25.0 GS/s
≤3.5 GHz instruments: 10.0 GS/s
HORizontal:ROLL AUTO
Mask Default Values
The following table lists the Mask factory default setup values.
Command Default Va
lues
MASK:AUT
OAdjust
10
MASK:AUT
OAdjust:HDELTA
10
MASK:AU
TOAdjust:VDELTA
10
MASK:AU
TOSet:AUTOAdjust
1
MASK:A
UTOSet:HPOS
1
MASK:
AUTOSet:HSCAle
1
MASK:
AUTOSet:MODe
MANUAL
MASK
:AUTOSet:OFFSETAdj
1
MASK
:AUTOSet:STANdard
NONE
MAS
K:AUTOSet:TRIGger
1
MAS
K:AUTOSet:VPOS
1
MA
SK:AUTOSet:VSCAle
1
M
ASK:COUNt:STATE
0
M
ASK:DISplay
1
MASK:FILTer
0
MASK:HIGHLIG HT Hits
1
MASK:INVert
0
MASK:LOCk
1
MASK:MARgin:PERCent
5.0000
MASK:MARgin:STATE
0
MASK:MASKPRE:AMPlitude
100.0000E-3
MASK:MASKPRE:HSCAle
200.0000E-9
MASK:MASKPRE:HTRIGPOS
500.0000E-3
MASK:MASKPRE:PATTERNBITS
1
MASK:MASKPRE:PRESAMPBITS
0
MASK:MASKPRE:RECOrdlength
5000
MASK:MASKPRE:TRIGTOSAMP
0.0000
MASK:MASKPRE:VOFFSet
0.0000
MASK:MASKPRE:VPOS
0.0000
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual C-5
