Tektronix DPO70000 Series Programmer's Manual

Appendix C: Factory Default Setup Values
Command Default Values
MASK:MASKPRE:VSCAle
1.0000E-3
MASK:MASKPRE:WIDth
0.0000
MASK:POLarity POSITIVE
MASK:SOUrce CH1
MASK:STANdard NONE
MASK:STOPOnviolation
0
MASK:TESt:BEEP:COMPLetion
0
MASK:TESt:BEEP:FAILure
0
MASK:TESt:DELay
0.0000
MASK:TESt:HARDCopy
0
MASK:TESt:LOG:FAILure
0
MASK:TESt:REPeat
0
MASK:TESt:SAMple:THReshold
1
MASK:TESt:SAVEWFM
0
MASK:TESt:SAVEWFM:FILEName “C:/TekScope/Waveforms/”
MASK:TESt:SRQ:CO M PLetion
0
MASK:TESt:SRQ :FAILure
0
MASK:TESt:STATE
0
MASK:TESt:STOP:FAILure
0
MASK:TESt:THReshold
1
MASK:TESt:WAVEform
20
MASK:USER:AMPlitude
100.0000E-3
MASK:USER:BITRate
1544000
MASK:USER:HSCAle
200.0000E-9
MASK:USER:HTRIGPOS
500.0000E-3
MASK:USER:LABel
“User Mask”
MASK:USER:PATTERNBITS
1
MASK:USER:PRES AMPBITS
0
MASK:USER:RECOrdlength
5000
MASK:USER:TRIGTOSAMP
0.0000
MASK:USER:VOFFSet
0.0000
MASK:USER:VPOS
0.0000
MASK:USER:VSCAle
1.0000E-3
MASK:USER:WIDth
0.0000
Math Default Values
The following table lists the Math factory default s etup values.
C-6 DPO7000, DPO70000/B and DSA7000/B S eries Programmer Manual
