Tektronix DPO70000 Series Programmer's Manual

Appendix C: Factory Default Setup Values
Command Default Values
MATHVAR:VAR<
x>
0.0000
MATH<x>:DEFine “”
MATH<x>:LABel:NAMe “”
MATH<x>:LABel:XPOS
1.0000
1 = 600.0000
E-3
2 = 200.0000E-3
3 = -200.0000E-3
MATH<x>:LABel:YPOS
4 = -600.00
00E-3
MATH<x>:NUMAVg 2
MATH<x>:SPECTral:CENTER
625.0000E+6
MATH<x>:SPECTral:GATEPOS
0.0000
MATH<x>:SPECTral:GATEWIDTH
2.0000E-6
MATH<x>:SPECTral:LOCk
0
MATH<x>:SPECTral:MAG
DB
MATH<x>:SPECTral:PHASE DEGREES
MATH<x>:SPECTral:REFLevel
20.0000
MATH<x>:SPECTral:REFLEVELOffset
223.6000E-3
MATH<x>:SPECTral:RESBw
1000.0000E+3
MATH<x>:SPECTral:SPAN
1.2500E+9
MATH<x>:SPECTral:SUPPress
-200.0000
MATH<x>:SPECTral:UNWRap
0
MATH<x>:SPECTral:WINdow GAUSSIAN
MATH <x>:UNITString
“V”
MATH<x>:VERTical:POSition
0.0000
MATH<x>:VERTical:SCAle
1.0000
Measurement Default
Values
The following table lists the Measurement factory default setup values.
Command Default Values
MEASUrement:GATing OFF
MEASUrement:IMMed:DELay:DIREction FORWARDS
MEASUrement:IMMed:DELay:EDGE[1] RISE
MEASUrement:IMMed:DELay:EDGE2 RISE
MEASUrement:IMMed:MET Hod HISTOGRAM
MEASUrement:IMMed:NOISe HIGH
MEASUrement:IMMed:RE FLevel:ABSolute:HIGH
0.0000
MEASUrement:IMMed:RE FLevel:ABSolute:LOW
0.0000
MEASUrement:IMMed:RE F Level:AB Solute:M ID <x>
0.0000
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual C-7
