Tektronix DPO70000 Series

Appendix C: Factory Default Setup Values
Command Default Values
MEASUrement:IMMed:R EF Level:M ET Hod PERCENT
MEASUrement:IMMed:R E F Level:P ERCent:HIGH
90.0000
MEASUrement:IMMed:R EF Level:PERCent:LOW
10.0000
MEASUrement:IM Med:R EF Level:PERCent:MID<x >
50.0000
MEASUrement:IMMed:S OU rce<x> CH1
MEASUrement:IMMed:S O U rce<x>:S IGType PULSE
MEASUrement:IMMed:T YPe
UNDEFINE
D
MEASUrement:MEAS<x>:DELay:DIREction FORWARDS
MEASUrement:MEAS<x>:DELay:EDGE<x> RISE
MEASUrement:MEAS<x>:METHod HISTOGRAM
MEASUrement:MEAS<x>:NOISe HIGH
MEASUrement:MEAS<x>:REFLevel:ABSolute:HIGH
0.000
0
MEASUrement:MEAS<x>:REFLevel:ABSolute:LOW
0.000
0
MEASUrement:MEAS<x>:REFLevel:ABSolute:MID<x>
0.00
00
MEASUrement:IMMed:R EF Level:M ET Hod PERCENT
MEASUrement:MEAS<x>:REFLevel:PERCent:HIGH
0.0
000
MEASUrement:MEAS<x>:REFLevel:PERCent:LOW
0.
0000
MEASUrement:MEAS<x>:REFLevel:PERCent:MID<x>
0.
0000
MEASUrement:MEAS<x>:SOUrce<x> CH1
MEASUrement:MEAS<x>:SOUrce<x>:SIGType PULSE
MEASUrement:MEAS<x>:STATE
0
MEASUrement:MEAS<x>:TYPe
UNDEFINED
MEASUrement:STATIstics:MODe
ALL
MEASUrement:STATIstics:WEIghting
32
Miscellaneous Default
Values
The following table lists the Miscellaneous factory default setup values.
Command Default Values
AUXout:EDGE FALLING
AUXout:SOUrce ATRIGGER
CMDBatch 1(ON)
HEADer
1(ON)
LOCk NONE
ROSc:TRACking
INTERNAL
VERBose
1(ON)
C-8 DPO7000, DPO70000/B and DSA7000/B S eries Programmer Manual
