Tektronix DPO70000 Series Programmer's Manual

Appendix C: Factory Default Setup Values
Save and Recall Default
Settings
The following t
able lists the Save and Recall factory default setup values.
Command Default Values
RECAll:SETUp:DESKew OFF
SAVe:WAVEform:FILEFormat
INTERNAL
Search and Mark Default
Values
The following table lists the Search and Mark factory default setup value s.
Command Default Values
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:AUTOBitrate
AUTO
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:AUTOReflevel
AUTO
SEARCH:SEARCH<x>:TRIGger:A:
DDRMem o ry:BITRate
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:DATASource
CH1
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:HIG H
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:LOW
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:MID
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:STROBE:HIGH
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:STROBE:LOW
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:STROBE:MID
9.9000E+36
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:STANdard
DDR3
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:STROBEsource
CH2
TekLink Default Values
The following table lists the TekLink factory default setup values.
Command Default Values
TEKLink:CONNection? OFF
TEKLink:REFClk
INTERNAL
TRIGger:MULTiscope:ALIGN DONE
TRIGger:MULTiscope:ALIGN:COMPleted? DONE
TRIGger:MULTiscope:LOGic DONE
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual C-9
