Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
TRIGger:{A|B}:PULse :RU NT:POLarity:
CH<x>
Sets or returns the polarity for the A or B
pulse runt trigger for the channel
TRIGger:{A|B}:PULse :RU NT:QUAlify Sets o r returns the polarity for the A or B
pulse runt tr
igger
TRIGger:{A
|B}:PULse:RUNT:THReshold:
BOTh
Sets the upp
er and lower switching thresholds
for the A pulse runt trigger
TRIGger:{A|B}:PULse:RUNT:THReshold:
HIGH
Sets or returns the upper limit for the A pulse
runt trigger
TRIGger:{A|B}:PULse:RUNT:THReshold:
LOW
Sets or returns the lower limit for the A pulse
runt trig
ger
TRIGger:
{A|B}:PULse:RUNT:THReshold?
Returns t
he upper and lower thresholds for
the A pulse runt trigger
TRIGger:{A|B}:PULse :RU NT:WHEn Sets or returns the type of pulse width the
trigger checks for when it uncovers a runt
TRIGger:{A|B}:PULse :RU NT:WIDth Sets or returns the minimum width for A pulse
runt tr
igger
TRIGg
er:{A|B}:PULse:RUNT?
Returns the current A runt pulse trigger
param
eters
TRIGg
er:{A|B}:PULse:SOUrce
Sets o
r returns the source for the A pulse
trigger
TRIGger:{A|B}:PULse:TIMEOut:POLarity Sets or returns the polarity for the A pulse
timeout trigger
TRIGger:{A|B}:PULse :TIM EOut:POLarity:
CH<
x>
Sets or returns the polarity for the A or B
pul
se timeout trigger for the channel
TR
IGger:{A|B}:PULse:TIM EOut:QUAlify
Se
ts or returns the timeout trigger
qualifications
TRIGger:{A|B}:PULse :TIM EOut:T IMe Sets or returns the pulse timeout trigger time
TRIGger:{A|B}:PULse:TIMEOut? Returns the parameters for the A pulse
timeout trigger
TRIGger:{A|B}:PULse:TRANsition:
DELTATime
Sets or returns the delta time used in
calculating the transition value
TRIGger:{A|B}:PULse:TRANsition:POLarity Sets o r returns the polarity for the A pulse
transition trigger
TRIGger:{A|B}:PULse:TRANsition:POLarity:
CH<x>
Sets or returns the polarity for the A or B
pulse transition trigger for the channel
TRIGger:{A|B}:PULse:TRANsition:QUAlify Sets o r returns the transition trigger
qualifications
TRIGger:{A|B}:PULse:TRANsition:
THReshold:BOTh
Sets the upper and lower thresholds for the
transition trigger
TRIGger:{A|B}:PULse:TRANsition:
THReshold:HIGH
Sets or returns the upper transition trigger
threshold
TRIGger:{A|B}:PULse:TRANsition:
THReshold:LOW
Sets or returns the lower transition trigger
threshold
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-59
