Command Groups
Command
Description
TRIGger:{A|B}:PULse:TRANsition:
THReshold?
Returns the up
per and lower threshold limits
for the transition time trigger
TRIGger:{A|B}:PULse:TRANsition:WHEn Sets or queries whether to check for a
transitioni
ng signal that is faster or slower
than the s pecified delta time for the transition
time trigger
TRIGger:{A|B}:PULse:TRANsition?
Returns the delta time, polarity, and both
upper and lower threshold limits for the
transition
time trigger
TRIGger:{
A|B}:PULse:WIDth:HIGHLim it
Sets or ret
urns the upper limit for the A pulse
width trigger
TRIGger:{A|B}:PULse:WIDth:LO W Lim it Sets or returns the lower limit for the pulse
width trigger
TRIGger:{A|B}:PULse:WIDth:P OLarity Sets or returns the polarity for the pulse width
trigger
TRIGger
:{A|B}:PULse:WIDth:POLarity:
CH<x>
Sets or r
eturns the polarity for the A or B
pulse width trigger for the channel
TRIGger:{A|B}:PULse:WIDth:QUAlify S ets or returns the pulse width trigger
qualifications
TRIGger:{A|B}:PULse:WIDth:WHEn Sets or returns the c riteria for width
speci
fication of pulse width trigger events
TRIG
ger:{A|B}:PULse:WIDth?
Returns the trigger pulse width parameters
TRIG
ger:{A|B}:PULse:WINdow:EVENT
Sets
or queries the window trigger event
TRI
Gger:{A|B}:PULse:WINdow:QUAlify
Set
s or returns the window trigger
qualifications
TRIGger:{A|B}:PULse:WINdow:THReshold:
BOTh
Sets both w indow thresholds
TRIGger:{A|B}:PULse:WINdow:THReshold:
H
IGH
Sets or returns high window threshold
T
RIGger:{A|B}:PULse:WINdow:THReshold:
LOW
S
ets or returns low w indow threshold
TRIGger:{A|B}:PULse:WINdow:THReshold? Returns the upper and lower thresholds for
the pulse window trigger
TRIGger:{A|B}:PULse:WINdow:WIDTH S ets or returns minimum width of violation
TRIGger:{A|B}:PULse:WINdow?
Returns the current window pulse trigger
parameters
TRIGger:{A|B}:PULse?
Returns the pulse trigger parameters
TRIGger:{A|B}:UPPerthreshold:CH<x> Sets or queries the CH<x> upper trigger level
for TRIGger:LVLSrcpreference
TRIGger:A:COMMunication:
{AMI|HDB3|B3ZS|B6ZS|B8ZS}:PULSEForm
Sets or returns the selected communication
pulse form
2-60 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
