Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
TRIGger:A:COMMunication:
{AMI|HDB3|B3ZS|B6ZS|B8ZS}:THReshold:
HIGH
Sets the communication threshold high level
TRIGger:A:C
OMMunication:
{AMI|HDB3|B3ZS|B6ZS|B8ZS}:THReshold:
LOW
Sets the comm
unication threshold low level
TRIGger:A:COMMunication:BITRate Sets or returns the communication bit rate
TRIGger:A:COMMunication:CLOCk:
POLarity
Sets or returns the polarity of the clock signal
TRIGger:
A:COMMunication:CMI:
PULSEForm
Selects t
he CMI pulse form
TRIGger:A:COMMunication:CODe Sets the communication signal code
TRIGger:A:COMMunication:SOUrce Sets the communication source channel
TRIGger:A:COMMunication:SOUrce:TYPe Sets the type of communication source
channel
TRIGger:A:COMMunication:STANdard Selects the communication standard that
ident
ifies the code and bit rate
TRIGg
er:A:HOLDoff:ACTUal?
Retur
ns the holdoff time actually used by the
A trigger
TRIGger:A:HOLDoff:BY Sets or returns the type of holdoff for the A
trigger
TRIGger:A:HOLDoff:TIMe Sets or returns the A trigger holdoff time
TRIGger:A:HOLDoff? Returns the A trigger holdoff parameters
TRIGger:A:LOGIc? Returns all of the A trigger logic parameters
TRIGger:A:MODe Sets or returns the A trigger mode
TRIGger:A:PULse:W INdow:POLarity Sets or queries the pulse trigger window
p
olarity of the selected trigger Source
TRIGger:A:PULse:W INdow:POLarity:
CH<x>
Sets or queries the pulse trigger window
polarity of the specified channel
TRIGger:A:TYPe Sets or returns the type of A trigger
TRIGger:A:VIDeo:CUSTom? Returns the custom video parameters for the
A trigger
TRIGger:A:VIDeo:CU S Tom :F O R Mat Sets or returns the video scan format when
the video standard is set to Custom
TRIGger:A:VIDeo:CUSTom:LINEPeriod Sets or returns the custom video line period
TRIGger:A:VIDeo:CUSTom:SYNCInterval Sets or returns the custom video sync interval
TRIGger:A:VIDeo:FIELD Sets or returns the video field trigger
TRIGger:A:VIDeo:HOLdoff:FIELD Sets or returns the trigger holdoff in video
field units
TRIGger:A:VIDeo:LINE Sets or returns the trigger delay as a number
of video lines
TRIGger:A:VIDeo:POLarity Sets o r returns the polarity of the video trigger
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-61
